Features
ACT™ CONTROL TECHNOLOGY
Airflow Control Technology (ACT) allows the installer to set the maximum fan CFM to align with local codes and regulations.
Additional Features
ICON TOUCH™ CONTROLS
Seamlessly integrates into the hood’s stainless steel canopy and allows users to easily control the 5-speeds, delay-off function, auto reminders and Airflow Control Technology.
Specifications
General
Series Name
• Siena
• Core Collection
• Core Collection
Blower Included
Yes
Airflow
400 CFM
Style
Chimney
Color
Stainless Steel
Manufacturer Color
Stainless Steel
Installation
Wall Mount
Features
Technologies
• ACT™ Technology
• ICON Touch® Controls
• LumiLight LED Lighting
• ICON Touch® Controls
• LumiLight LED Lighting
Ducting Information
• Vertical Internal Blower: 8" Round
• Horizontal Internal Blower: 8" Round
• Horizontal Internal Blower: 8" Round
Speeds
• 5 Speed Levels
• Blower CFM (Min. - Max.): 200 - 400
• Sones (Min. - Max.): 2 - 6.5
• ACT 290 CFM (Min. - Max.): 200 - 290
• Blower CFM (Min. - Max.): 200 - 400
• Sones (Min. - Max.): 2 - 6.5
• ACT 290 CFM (Min. - Max.): 200 - 290
Additional Information
• Auto Delay-Off
• Lighting: LumiLight LED, 7W x2
• Filters: Hybrid Baffle x2
• Extension Duct Cover Option: Up to 12' Ceiling
• Lighting: LumiLight LED, 7W x2
• Filters: Hybrid Baffle x2
• Extension Duct Cover Option: Up to 12' Ceiling
Electrical Information
Information
120V, 60Hz at Max. 1.3A
Certifications and Approvals
Energy Star Certified
Yes
Information
cULus
Accessories
Optional
• Extension Duct Cover: Z1C-00SI
• Stainless Steel Telescopic Backsplash: AK1710
• Stainless Steel Telescopic Backsplash: AK1710
Dimensions
Class Width
30"
Width
29.94 inch(es) / 76.04 cm
Height
27.5 inch(es) / 69.85 cm
Depth
21.94 inch(es) / 55.72 cm
Additional Dimensions
Mounting Height Range: 24" - 34"
Warranty
Warranty
• 1-Year warranty on labor
• 3-Year warranty on parts
• 3-Year warranty on parts
UPC
UPC#
646328011603
