Specifications
General
Series Name
Masterpiece
Style
Downdraft
Color
Stainless Steel
Installation
Built-In
Features
Dishwasher-Proof Filters
Yes
Ducting Information
• Diameter of air duct - internal: 8"
• Diameter of air duct - external: 6", 8" or 10"
• Diameter of air duct - external: 6", 8" or 10"
Speeds
3-stage settings
Additional Information
• 15" telescopic design rises to capture heat, smoke, grease, and steam
• Flexible discharge design gives 6 configurations to maximize space
• Remote or inline blowers to reduce noise, integral for topperformance
• Features automatic mode, delay shut-off, and check filter light
• Recirculation kit available, use with induction/electric cooktops only
• Flexible discharge design gives 6 configurations to maximize space
• Remote or inline blowers to reduce noise, integral for topperformance
• Features automatic mode, delay shut-off, and check filter light
• Recirculation kit available, use with induction/electric cooktops only
Electrical Information
Information
• 120 V
• 60 Hz
• 10 A
• 60 Hz
• 10 A
Accessories
Optional
• CVTSIDE6 – 6" Side / Rear Transition
• CVTSIDE8 – 8" Side / Rear Transition
• CVTSIDE10 – 10" Side / Rear Transition
• CVTFRONT6 – 6" Round Front Plate
• CVTFRONT8 – 8" Round Front Plate
• CVTFRONT10 – 10" Round Front Plate
• CVDUCT2 – 2' Rectangular Duct
• CVTRECT2 – Transition for Rectangular Duct
• CVTSIDE8 – 8" Side / Rear Transition
• CVTSIDE10 – 10" Side / Rear Transition
• CVTFRONT6 – 6" Round Front Plate
• CVTFRONT8 – 8" Round Front Plate
• CVTFRONT10 – 10" Round Front Plate
• CVDUCT2 – 2' Rectangular Duct
• CVTRECT2 – Transition for Rectangular Duct
Dimensions
Class Width
30"
Width
31 inch(es) / 78.74 cm
Height
44.37 inch(es) / 112.7 cm
Depth
2.75 inch(es) / 6.99 cm
Weight
36.99 lb(s) / 16.78 kg
Additional Dimensions
Height of the rise: 15"
Warranty
Warranty
Limited 2 Years Parts and Labor
UPC
UPC#
825225960881
