Specifications
General
Series Name
700 Series
Color
Black
Manufacturer Color
Glossy Black with Aluminium Trim
Fuel Type
Electric
Type
Built-In
Cooktop
Burners/Elements
4
Power Output
• Right Front Element: 1200W
• Left Front Element: 1200W
• Left Rear Element: 1900W (1100+800W)
• Right Rear Element: 1200W
• Left Front Element: 1200W
• Left Rear Element: 1900W (1100+800W)
• Right Rear Element: 1200W
Burner/Element Size
• Right Front Element: 5 3/4"
• Left Front Element: 5 3/4"
• Left Rear Element: 7-5/8" - 4-7/8"
• Right Rear Element: 5 3/4"
• Left Front Element: 5 3/4"
• Left Rear Element: 7-5/8" - 4-7/8"
• Right Rear Element: 5 3/4"
Elements
Smoothtop
Surface Features
Elegant Ceramic glass surface
Features
Control Lock
Yes
Digital Display
Yes
Additional Information
• Slide touch control for power setting
• Melt Function
• Residual heat and Power on Indicators
• Digital Minute Minder
• Independent timer for each zone
• Pause function
• Failure Codes Indication
• Digital Display for Power Level
• Automatic Heat-up Time
• Melt Function
• Residual heat and Power on Indicators
• Digital Minute Minder
• Independent timer for each zone
• Pause function
• Failure Codes Indication
• Digital Display for Power Level
• Automatic Heat-up Time
Electrical Information
Information
• KW/Amps rating at 240V, 60Hz: 5.50kW - 22.9 Amps
• KW/Amps rating at 208V, 60Hz: 4.10kW - 19.7Amps
• KW/Amps rating at 208V, 60Hz: 4.10kW - 19.7Amps
Certifications and Approvals
ADA Compliant
Yes
Dimensions
Class Width
30"
Width
30.25 inch(es) / 76.84 cm
Height
2.75 inch(es) / 6.99 cm
Depth
21 inch(es) / 53.34 cm
Shipping Dimensions
Weight
33 lb(s) / 14.97 kg
