Features
DELAYED AUTO-OFF
Automatically turns the fan off after a set time (varies by the hood).
DIRECT VENT
Top or direct rear venting (horizontal) to eliminate the need for extra ducting.
ENERGY DIFFUSER
A motor that improves efficiency and allows for longer duct runs.
LED LIGHT
Energy efficient and cool to the touch LED lighting.
REMOTE CONTROL (OPTIONAL)
Control all features of the hood from the convenience of a wireless remote control. (sold separately)
INTENSIVE SPEED
Turns on at the highest speed for 10 minutes.
Specifications
General
Series Name
Classica Plus
Blower Included
Yes
Airflow
600 CFM
Style
Chimney
Color
Stainless Steel
Manufacturer Color
Stainless Steel
Installation
Wall Mount
Features
Dishwasher-Proof Filters
Yes
Technologies
Variable Air Management technology
Ducting Information
6" round (Top)
Speeds
4 Speeds:
• Motor Class: 295, 395, 600
• CFM: 150 / 295 / 395 / 560
• Noise (Sones): 2.8 / 4.3 / 6.0 / 7.5
• Power Watts: 210 / 240 / 300 / 320
• Motor Class: 295, 395, 600
• CFM: 150 / 295 / 395 / 560
• Noise (Sones): 2.8 / 4.3 / 6.0 / 7.5
• Power Watts: 210 / 240 / 300 / 320
Additional Information
• One piece body construction
• Dishwasher-safe mesh grease filters
• Electronic controls with white LED
• Energy-efficient LED lighting
• Delay Shut-Off: 15 Minutes
• Intensive Speed: 10 Minutes
• Dishwasher-safe mesh grease filters
• Electronic controls with white LED
• Energy-efficient LED lighting
• Delay Shut-Off: 15 Minutes
• Intensive Speed: 10 Minutes
Accessories
Included
Power cord
Optional
• FILTER1: Charcoal Filter Kit
• FILTER1LL2: Long Lasting Charcoal Filter Kit
• WIREBOX: Fixed Wire Box
• HIGHCLPL: Chimney Kit (up to 11' 8" ceiling)
• DUCTCLPL: Ductless Kit
• REMORIG: Wireless Remote Control
• MUDAMPER6: 6" Make-up Air Kit
• MUDAMPER8: 8" Make-up Air Kit
• FILTER1LL2: Long Lasting Charcoal Filter Kit
• WIREBOX: Fixed Wire Box
• HIGHCLPL: Chimney Kit (up to 11' 8" ceiling)
• DUCTCLPL: Ductless Kit
• REMORIG: Wireless Remote Control
• MUDAMPER6: 6" Make-up Air Kit
• MUDAMPER8: 8" Make-up Air Kit
Dimensions
Class Width
36"
Width
35.37 inch(es) / 89.85 cm
Height
33.69 inch(es) / 85.57 cm
Depth
18.5 inch(es) / 46.99 cm
Additional Dimensions
• Canopy Depth - Height: 18 1/2" D x 9 13/16" H
• Ceiling Height: Min 24" OFF - 7' 911/16", Max. 30" OFF - 9' 51/4"
• Ceiling Height: Min 24" OFF - 7' 911/16", Max. 30" OFF - 9' 51/4"
Warranty
Warranty
Limited 2 Years
