Features
PERIMETER ASPIRATION
Air is forced through narrow slots around the perimeter of the center panel greatly improving contaminant extraction.
EASY SNAP MOUNTING CLIPS
Installation with easy with built-in adjustable clips that tighten onto the sides of the cabinet floor.
LED LIGHT
Energy efficient and cool to the touch LED lighting.
REMOTE CONTROL (OPTIONAL)
Control all features of the hood from the convenience of a wireless remote control. (sold separately)
SOUND PRO
Reducing turbulence and swirls in the internal airflow, the new blowers technology succeeds in both limiting noise and improving the sound quality of the hood.
INTENSIVE SPEED
Turns on at the highest speed for 10 minutes.
Specifications
General
Series Name
Inca Lux
Blower Included
Yes
Airflow
600 CFM
Style
Custom Insert
Color
Stainless Steel
Manufacturer Color
Stainless Steel
Installation
Built-In
Features
Dishwasher-Proof Filters
Yes
Technologies
• Variable Air Management Technology
• Perimeter Aspiration
• Sound PRO Motor
• Perimeter Aspiration
• Sound PRO Motor
Ducting Information
Top 6" Round
Speeds
• 4-SPEED: 1 / 2 / 3 / BOOST
• CFM: 150 / 295 / 395 / 560
• Noise (Sones): 2.8 / 4.3 / 6.0 / 7.5
• Power Watts: 250 / 290 / 350 / 400
• CFM: 150 / 295 / 395 / 560
• Noise (Sones): 2.8 / 4.3 / 6.0 / 7.5
• Power Watts: 250 / 290 / 350 / 400
Additional Information
• Controls: Electronic with white LED
• Lighting: LED Bar
• Bulbs: One - 4 Watt - 1 Level
• Grease Filter: Dishwasher-safe mesh with perimeter aspiration
• Easy Snap Clip Installation
• Controls: Electronic With White LED
• Intensive Speed: 10 Minutes
• Delay Shut-off: 15 Minutes
• Lighting: LED Bar
• Bulbs: One - 4 Watt - 1 Level
• Grease Filter: Dishwasher-safe mesh with perimeter aspiration
• Easy Snap Clip Installation
• Controls: Electronic With White LED
• Intensive Speed: 10 Minutes
• Delay Shut-off: 15 Minutes
Accessories
Included
Power Cord Included
Optional
• FILTER1: Charcoal Filter Kit
• FILTER1LL2: Long Lasting Charcoal Filter
• REMORIG: Wireless Remote Control
• WIREBOX3: Fixed Wiring Box
• MUDAMPER6: 6" Make-up Air Kit
• MUDAMPER8: 8" Make-up Air Kit
• FILTER1LL2: Long Lasting Charcoal Filter
• REMORIG: Wireless Remote Control
• WIREBOX3: Fixed Wiring Box
• MUDAMPER6: 6" Make-up Air Kit
• MUDAMPER8: 8" Make-up Air Kit
Dimensions
Class Width
21"
Width
20.5 inch(es) / 52.07 cm
Height
12.75 inch(es) / 32.39 cm
Depth
11.44 inch(es) / 29.05 cm
Additional Dimensions
• Cabinet Cut Out for 21"/ 28": 19 ½" W x 10 7/16" D
• Height Inside Cabinet: 12 3/4"
• Height Inside Cabinet: 12 3/4"
Warranty
Warranty
1-Year parts and labor
