Features
ACT™ CONTROL TECHNOLOGY
Airflow Control Technology (ACT) allows the installer to set the maximum fan CFM to align with local codes and regulations.
Additional Features
ICON TOUCH™ CONTROLS
Seamlessly integrates into the hood’s stainless steel canopy and allows users to easily control the 5-speeds, delay-off function, auto reminders and Airflow Control Technology.
Specifications
General
Series Name
Ravenna
Blower Included
Yes
Airflow
600 CFM
Style
Chimney
Color
Stainless Steel
Installation
Wall Mount
Features
Technologies
Airflow Control Technology™ (ACT™)
Ducting Information
Vertical Ducting
Speeds
5
Additional Information
• LumiLight LED, 6W x2
• Dual-Level Lighting
• Smoke Gray Glass Canopy
• ICON Touch® Controls
• Min. - Max. CFM: 200 - 600
• Min. - Max. Sones: 1 - 6
• ACT 390 CFM (Min. - Max.): 200 - 390
• ACT 290 CFM (Min. - Max.): 200 - 290
• Auto Delay-Off
• Aluminum Mesh filter
• Vertical Internal Blower: 6" Round
• Dual-Level Lighting
• Smoke Gray Glass Canopy
• ICON Touch® Controls
• Min. - Max. CFM: 200 - 600
• Min. - Max. Sones: 1 - 6
• ACT 390 CFM (Min. - Max.): 200 - 390
• ACT 290 CFM (Min. - Max.): 200 - 290
• Auto Delay-Off
• Aluminum Mesh filter
• Vertical Internal Blower: 6" Round
Electrical Information
Information
• 120V
• 60Hz at Max.
• 4A
• 60Hz at Max.
• 4A
Accessories
Optional
• Wireless Remote Control Kit: RC-0002
• Recirculating Kit: ZRC-00RV
• Duct Cover Extension: Z1C-00RV (SS)
• Make-Up Air Kit: MUA006A
• Recirculating Kit: ZRC-00RV
• Duct Cover Extension: Z1C-00RV (SS)
• Make-Up Air Kit: MUA006A
Dimensions
Class Width
30"
Width
30 inch(es) / 76.2 cm
Depth
19.75 inch(es) / 50.17 cm
Additional Dimensions
Mounting Height Range: 26"-34"
Warranty
Warranty
• 3 years parts
• 1 year labor
• 1 year labor
UPC
UPC#
646328010880
