Features
ACT™ CONTROL TECHNOLOGY
Airflow Control Technology (ACT) allows the installer to set the maximum fan CFM to align with local codes and regulations.
Additional Features
CLEANAIR FUNCTION
CleanAir Function will turn the hood on once every four hours for 10 minutes to ensure the air is properly recirculated.
POWERWAVE™ BLOWER
Zephyr PowerWave™ is designed to deliver best-in-class performance with unparalleled quiet operation, it is a breakthrough in kitchen technology. The first range hood blower with three-phase AC power, PowerWave™ has unique aerodynamic blades to help move up to 750 CFM of air while minimizing noise and improving efficiency. PowerWave™ is also versatile by allowing you to combine two blowers together to achieve 1,300 CFM, making it the most powerful dual-internal blower system on the market. It’s a leap forward in range hood performance that can only have been imagined by Zephyr.
Specifications
General
Series Name
Roma Pro
Blower Included
Yes
Airflow
750 CFM
Style
Chimney
Color
Stainless Steel
Installation
Wall Mount
Features
Technologies
• Airflow Control Technology™ (ACT™)
• PowerWave™ Blower
• PowerWave™ Blower
Ducting Information
• Vertical Single Internal Blower: 8" Round
• Vertical Dual Internal Blower: 10" Round
• Vertical Dual Internal Blower: 10" Round
Speeds
• Speed Levels: 6**
• Included Single Blower: 200-750 CFM, 0.5-7 Sones
• ACT 590*: 200-590 CFM
• ACT 390*: 200-390 CFM
• ACT 290*: 200-290 CFM
• *ACT™ only available with a single internal blower.
• **When ACT™ is enabled the number of fan speeds will be reduced to maximum of 3 speeds
• Included Single Blower: 200-750 CFM, 0.5-7 Sones
• ACT 590*: 200-590 CFM
• ACT 390*: 200-390 CFM
• ACT 290*: 200-290 CFM
• *ACT™ only available with a single internal blower.
• **When ACT™ is enabled the number of fan speeds will be reduced to maximum of 3 speeds
Additional Information
• Auto Delay-Off
• CleanAir Function
• Directional Lighting: LumiLight LED, 6W x4
• Dual-Level Lighting
• Filters: Pro Baffle x3
• Grease Collection Tray
• Duct Cover Extension Option
• CleanAir Function
• Directional Lighting: LumiLight LED, 6W x4
• Dual-Level Lighting
• Filters: Pro Baffle x3
• Grease Collection Tray
• Duct Cover Extension Option
Electrical Information
Information
• AC POWER (Single Blower): 120V, 60Hz at Max. 5A
• AC POWER (Dual Blower): 120V, 60Hz at Max. 8A
• AC POWER (Dual Blower): 120V, 60Hz at Max. 8A
Certifications and Approvals
Information
ADA Compliant with remote accessory
Accessories
Optional
• Wireless Remote Control: 14000005
• Dual Internal Blower: PBD-1300B
• Duct Cover Extension: Z1C-00RP
• Stainless Steel Telescopic Backsplash: AK1716
• Make-Up Air Kit (Single Blower): MUA008A
• Make-Up Air Kit (Dual Blower): MUA010A
• Dual Internal Blower: PBD-1300B
• Duct Cover Extension: Z1C-00RP
• Stainless Steel Telescopic Backsplash: AK1716
• Make-Up Air Kit (Single Blower): MUA008A
• Make-Up Air Kit (Dual Blower): MUA010A
Dimensions
Class Width
48"
Width
48 inch(es) / 121.92 cm
Height
14.5 inch(es) / 36.83 cm
Depth
24 inch(es) / 60.96 cm
Warranty
Warranty
3 years parts, 1 year labor
UPC
UPC#
646328010866
