Features
LED LIGHTING (DUAL LEVEL)
Dual level LED light strip illuminates your cooking area.
CONVERTIBLE.
Vent out with additional charcoal filters (FT0130) and recirculation kit (ARC3001P) (not included).
5 LAYER ALUMINUM MESH FILTER
The 5-layer aluminum mesh filter, featured in our air purifiers, guarantees superior particle capture. This means you enjoy cleaner air and an extended filter life thanks to its durable aluminum construction.
5-MINUTE AUTOMATIC DELAY-OFF
Our devices are designed with a 5-minute automatic delay-off feature. This not only conserves energy but also enhances safety by preventing overheating, giving you peace of mind.
NOISE LEVEL
Keeps noise level at a maximum of 65 decibels. The hood features three speeds offering quiet operation for each - 47 dBA, 55 dBA, and 65 dBA
CUSTOMIZABLE
Duct Cover Extension(RHDC01AP) extends to accommodate up to 12 ft ceilings (not included)
Specifications
General
Series Name
Contemporary P-Shape
Blower Included
Yes
Airflow
530 CFM
Style
Chimney
Color
Stainless Steel
Manufacturer Color
Stainless Steel
Installation
Wall Mount
Features
Ducting Information
7" Round
Speeds
3 Speeds
Additional Information
• Lighting: LED light x 2
• Noise level (Max.): 67 dB
• Filter type: 430SS Baffle filter
• Blower type: Internal
• Control type: Button, no auto shut off No, delayed shut off
• Low: 530 CFM 50dBA
• Medium: 700 CFM 59dBA
• High 800: CFM 67dBA
• Noise level (Max.): 67 dB
• Filter type: 430SS Baffle filter
• Blower type: Internal
• Control type: Button, no auto shut off No, delayed shut off
• Low: 530 CFM 50dBA
• Medium: 700 CFM 59dBA
• High 800: CFM 67dBA
Electrical Information
Information
• 120 V
• 60 Hz
• 5 A
• 60 Hz
• 5 A
Certifications and Approvals
Information
ETL
Dimensions
Class Width
30"
Width
30 inch(es) / 76.2 cm
Height
11 inch(es) / 27.94 cm
Depth
22 inch(es) / 55.88 cm
Weight
55.01 lb(s) / 24.95 kg
Shipping Dimensions
Weight
66.49 lb(s) / 30.16 kg
Warranty
Warranty
2 Years Parts and Labor
