Features
SOFTCLOSE® DOOR HINGES
This exclusive, innovative door hinge allows for a 115° door opening and can be positioned to stop at a 90° angle.
OPEN DOOR ASSIST
Thermador Auto Door Opening technology allows you to either push or pull to open the refrigerator door, adding a personalized touch.
PRESENTER SHELF
Let your favorite bottles catch the eye. A prominent display section allows you to place select wines front and center, so you can easily share with guests.
Additional Features
FREEDOM® HINGE
Freedom® hinge enables true flush design
3 ZONE TEMPERATURE CONTROL
From Chardonnay to Pinot to Rosé, store all of your wines at the optimum temperature. The Thermador 24" Wine Column features UV glass and is equipped with three separate zones for precise temperature control - for up to 98 bottles of wine.
Specifications
General
Series Name
Freedom® Collection
Bottles
92
Number of Racks
11
Temperature Zones
3
Temperature Settings
• Zone 1 (Upper Zone): 41°F (5°C) to 68°F (20°C)
• Zone 2 (Middle Zone): 41°F (5°C) to 68°F (20°C)
• Zone 3 (Lower Zone): 41°F (5°C) to 68°F (20°C)
• Zone 2 (Middle Zone): 41°F (5°C) to 68°F (20°C)
• Zone 3 (Lower Zone): 41°F (5°C) to 68°F (20°C)
Installation
Built-In
Type
Cooler
Size
Full Size
Color
Panel Ready
Manufacturer Color
Panel Ready (custom panels sold separately)
Hinge
Right
Features
Technologies
• Home Connect™ (Wi-Fi Enabled)
• SoftClose® Door
• SoftClose® Door
Digital Temperature Display
Yes
Glass Door
Yes
Interior Light
Yes
Reversible Door
Yes
Additional Information
• Tempered and UV-protective glass door
• TFT control panel
• Carbon air filter
• LED sidewall and theater lighting
• Number of shelves: 11
• Number of slide-out shelves: 8
• Shelf material: Wenge wood / Aluminum frame
• Full extension drawers @ 115° door opening angle
• Full extension drawers @ 90° door opening angle
• Presenter shelf with light
• Portable aluminum wine presenter
• Door open alarm
• Open door assist
• Plug type: 120V-3 Prong
• TFT control panel
• Carbon air filter
• LED sidewall and theater lighting
• Number of shelves: 11
• Number of slide-out shelves: 8
• Shelf material: Wenge wood / Aluminum frame
• Full extension drawers @ 115° door opening angle
• Full extension drawers @ 90° door opening angle
• Presenter shelf with light
• Portable aluminum wine presenter
• Door open alarm
• Open door assist
• Plug type: 120V-3 Prong
Electrical Information
Information
• Watts: 350 W
• Current: 15 A
• Volts: 110-120 V
• Frequency: 60 Hz
• Current: 15 A
• Volts: 110-120 V
• Frequency: 60 Hz
Certifications and Approvals
Energy Star Certified
Yes
Sabbath/Star-K
Yes
Accessories
Optional
• TFL24IW800: 24-Inch Flat Stainless Steel Door Panel, for use with handle
• TFL24IW905: 24-Inch Flat Stainless Steel Door Panel, handeless
• PR36HNDL20: 36-Inch Professional Series Handle
• MS36HNDL20: 36-Inch Masterpiece® Series Handle
• T24WINERK1: 24-Inch Wine Column Shelf, increases capacity to 99 bottles (750mL)
• FRAMEKIT10: Freedom® Frame Kit
• HEATRKIT20 – 13W @ 120V: Freedom® Heater Kit
• TFL24IW905: 24-Inch Flat Stainless Steel Door Panel, handeless
• PR36HNDL20: 36-Inch Professional Series Handle
• MS36HNDL20: 36-Inch Masterpiece® Series Handle
• T24WINERK1: 24-Inch Wine Column Shelf, increases capacity to 99 bottles (750mL)
• FRAMEKIT10: Freedom® Frame Kit
• HEATRKIT20 – 13W @ 120V: Freedom® Heater Kit
Dimensions
Width
23.75 inch(es) / 60.33 cm
Height
83.75 inch(es) / 212.73 cm
Depth (Without Handle)
24 inch(es) / 60.96 cm
Weight
344.01 lb(s) / 156.04 kg
Additional Dimensions
• Required cutout size (H x W x D): 84" x 24" x 25"
• Power cord length: 118"
• Power cord length: 118"
Shipping Dimensions
Weight
366.01 lb(s) / 166.02 kg
Warranty
Warranty
• 2 Year: Limited, entire appliance, parts and labor on any part of the refrigerator that fails because of a manufacturing defect
• 3rd to 6th Year: Limited warranty for sealed refrigeration system on parts and labor
• 7th to 12th Year: Limited warranty for sealed refrigeration system on parts only
• Lifetime: Limited warranty for stainless steel rust-through
• 3rd to 6th Year: Limited warranty for sealed refrigeration system on parts and labor
• 7th to 12th Year: Limited warranty for sealed refrigeration system on parts only
• Lifetime: Limited warranty for stainless steel rust-through
UPC
UPC#
825225960423
