Features
SOFTCLOSE® DOOR HINGES
This exclusive, innovative door hinge allows for a 115° door opening and can be positioned to stop at a 90° angle.
OPEN DOOR ASSIST
Thermador Auto Door Opening technology allows you to either push or pull to open the refrigerator door, adding a personalized touch.
PRESENTER SHELF
Let your favorite bottles catch the eye. A prominent display section allows you to place select wines front and center, so you can easily share with guests.
Additional Features
FREEDOM® HINGE
Freedom® hinge enables true flush design
Specifications
General
Series Name
Freedom® Collection
Bottles
58
Number of Racks
12
Temperature Zones
2
Temperature Settings
• Zone 1 (Upper Zone): 41°F (5°C) to 68°F (20°C)
• Zone 2 (Middle Zone): 41°F (5°C) to 68°F (20°C)
• Zone 2 (Middle Zone): 41°F (5°C) to 68°F (20°C)
Installation
Built-In
Type
Cooler
Size
Full Size
Color
Panel Ready
Manufacturer Color
Panel Ready (custom panels sold separately)
Hinge
Right
Features
Technologies
• Home Connect™ (Wi-Fi Enabled)
• SoftClose® Door
• SoftClose® Door
Digital Temperature Display
Yes
Glass Door
Yes
Interior Light
Yes
Reversible Door
Yes
Additional Information
• Tempered and UV-protective glass door
• TFT control panel
• Carbon air filter
• LED sidewall and theater lighting
• Number of shelves: 12
• Number of slide-out shelves: 10
• Shelf material: Wenge wood / Aluminum frame
• Full extension drawers @ 115° door opening angle
• Full extension drawers @ 90° door opening angle
• Presenter shelf with light
• Portable aluminum wine presenter
• Door open alarm
• Open door assist
• Plug type: 120V-3 Prong
• TFT control panel
• Carbon air filter
• LED sidewall and theater lighting
• Number of shelves: 12
• Number of slide-out shelves: 10
• Shelf material: Wenge wood / Aluminum frame
• Full extension drawers @ 115° door opening angle
• Full extension drawers @ 90° door opening angle
• Presenter shelf with light
• Portable aluminum wine presenter
• Door open alarm
• Open door assist
• Plug type: 120V-3 Prong
Electrical Information
Information
• Watts: 350 W
• Current: 15 A
• Volts: 110-120 V
• Frequency: 60 Hz
• Current: 15 A
• Volts: 110-120 V
• Frequency: 60 Hz
Certifications and Approvals
Energy Star Certified
Yes
Sabbath/Star-K
Yes
Accessories
Optional
• TFL18IW800: 18-Inch Flat Stainless Steel Door Panel, for use with handle
• TFL18IW905: 18-Inch Flat Stainless Steel Door Panel, handeless
• PR36HNDL20: 36-Inch Professional Series Handle
• MS36HNDL20: 36-Inch Masterpiece® Series Handle
• T18WINERK1: 18-Inch Wine Column Shelf, increases capacity to 62 bottles (750mL)
• FRAMEKIT10: Freedom® Frame Kit
• HEATRKIT20 – 13W @ 120V: Freedom® Heater Kit
• TFL18IW905: 18-Inch Flat Stainless Steel Door Panel, handeless
• PR36HNDL20: 36-Inch Professional Series Handle
• MS36HNDL20: 36-Inch Masterpiece® Series Handle
• T18WINERK1: 18-Inch Wine Column Shelf, increases capacity to 62 bottles (750mL)
• FRAMEKIT10: Freedom® Frame Kit
• HEATRKIT20 – 13W @ 120V: Freedom® Heater Kit
Dimensions
Width
17.75 inch(es) / 45.09 cm
Height
83.75 inch(es) / 212.73 cm
Depth (Without Handle)
24 inch(es) / 60.96 cm
Weight
287.99 lb(s) / 130.63 kg
Additional Dimensions
Required cutout size (H x W x D): 84" x 18" x 25"
Shipping Dimensions
Weight
317 lb(s) / 143.79 kg
Warranty
Warranty
• 2 Year: Limited, entire appliance, parts and labor on any part of the refrigerator that fails because of a manufacturing defect
• 3rd to 6th Year: Limited warranty for sealed refrigeration system on parts and labor
• 7th to 12th Year: Limited warranty for sealed refrigeration system on parts only
• Lifetime: Limited warranty for stainless steel rust-through
• 3rd to 6th Year: Limited warranty for sealed refrigeration system on parts and labor
• 7th to 12th Year: Limited warranty for sealed refrigeration system on parts only
• Lifetime: Limited warranty for stainless steel rust-through
UPC
UPC#
825225960393
