Features
EXTRALOW®
The ExtraLow® feature provides the widest variety of temperature control of any simmer system. It cycles on and off to maintain temperatures as low as 100°. Perfect for simmering delicate sauces or keeping food warm without scorching. THERMADOR EXCLUSIVE
PATENTED STAR BURNER
Exclusive, sealed 3-in-1 Star® Burner’s unique five-point design offers a reduced cold spot, faster time to boil and the ExtraLow feature. The coverage area allows for more ports and more flame distribution than a round burner. THERMADOR EXCLUSIVE
QUICKCLEAN BASE
The raised pedestal burner and porcelain maintop have been crafted for perfect integration and easy cleanup. A hand and sponge fit easily under each burner to wipe the surface clean and a teardrop emboss reduces food buildup near the base. THERMADOR EXCLUSIVE
Specifications
General
Series Name
Professional
Color
Stainless Steel
Manufacturer Color
Stainless Steel
Fuel Type
Natural Gas
Type
Rangetop
Cooktop
Burners/Elements
5
Power Output
• Power of Front Left Burner: 18,000 and XLO BTU
• Power of Back Left Burner: 8,000 and XLO BTU
• Power of Back Center Burner: 10,000 BTU
• Power of Back Right Burner: 8,000 BTU
• Power of Front Right Burner: 15,000 BTU
• Power of Back Left Burner: 8,000 and XLO BTU
• Power of Back Center Burner: 10,000 BTU
• Power of Back Right Burner: 8,000 BTU
• Power of Front Right Burner: 15,000 BTU
Burners
Sealed
Features
Technologies
• Patented Pedestal Star® Burner
• QuickClean Base®
• ExtraLow® Simmer Burners
• QuickClean Base®
• ExtraLow® Simmer Burners
Additional Information
• Patented Pedestal Star® Burner with QuickClean Base® designed for easy surface cleaning and superior heat spread for any size pan
• Precision simmering capabilities as low as 100°F (375 BTU) with 2 ExtraLow® Simmer burners
• LED Downlighting—hidden discreetly above the control panel provides functional and stylish illumination
• Five Star® Burners with an overall output of 59,000 BTUs
• Restaurant style metal knobs
• Cast iron grates
• Precision simmering capabilities as low as 100°F (375 BTU) with 2 ExtraLow® Simmer burners
• LED Downlighting—hidden discreetly above the control panel provides functional and stylish illumination
• Five Star® Burners with an overall output of 59,000 BTUs
• Restaurant style metal knobs
• Cast iron grates
Electrical Information
Information
• 120 V
• 60 Hz
• 15 A
• 60 Hz
• 15 A
Accessories
Optional
• Griddle Sits on Top of Grates Over 2 Star Burner: PAGRIDDLE
• 10" Low Backguard: PA30WLBC
• 12" Cutting Board: PA12CHPBLK
• Metallic Blue Knob Kit: PAKNOBLUWR
• Wok Ring: PWOKRINGHC
• 5 Burner LP Conversion Kit: PALPKITHW5
• 10" Low Backguard: PA30WLBC
• 12" Cutting Board: PA12CHPBLK
• Metallic Blue Knob Kit: PAKNOBLUWR
• Wok Ring: PWOKRINGHC
• 5 Burner LP Conversion Kit: PALPKITHW5
Dimensions
Class Width
30"
Width
29.94 inch(es) / 76.04 cm
Height
7.24 inch(es) / 18.4 cm
Depth
25.98 inch(es) / 66.0 cm
Weight
122 lb(s) / 55.34 kg
Additional Dimensions
Required Cutout Size (HxWxD): 7 11/16" x 29 1/8" x 22 13/16"
Warranty
Warranty
Limited 2 Years Parts and Labor
UPC
UPC#
825225926474
