Specifications
General
Series Name
Masterpiece®
Fuel Type
Electric
Color
Stainless Steel
Manufacturer Color
Stainless Steel
Total Capacity
1.6 cu. ft.
Oven Specifications
Technologies
CookSmart®
Programs
36 Cook Smart™ Auto Programs (Including European Convection, Hi and Lo Broil, Keep Warm, Frozen Foods) + Microwave
Clock
Yes
Control Lock
Yes
Convection
Yes
Additional Information
• Bake Element: 600 W
• Broil Element: 1,750 W
• Convection Element: 1,700 W
• Kitchen Timer
• ADA Compliant
• Turntable Diameter: 12 3/4"
• Turntable Diameter Ceramic Cookware Max.: 12 1/2"
• Specially crafted gray glass on stainless steel for a luxurious look and finish
• Designed for flexibility – standard or flush installation into kitchen cabinet
• 10 Levels Of Microwaveable Power
• Broil Element: 1,750 W
• Convection Element: 1,700 W
• Kitchen Timer
• ADA Compliant
• Turntable Diameter: 12 3/4"
• Turntable Diameter Ceramic Cookware Max.: 12 1/2"
• Specially crafted gray glass on stainless steel for a luxurious look and finish
• Designed for flexibility – standard or flush installation into kitchen cabinet
• 10 Levels Of Microwaveable Power
Electrical Information
Information
• 3,840 W
• 208 V /240 V
• 60 Hz
• 16 A
• 208 V /240 V
• 60 Hz
• 16 A
Accessories
Included
• Metal Turntable
• Cooking Rack
• Ceramic Cooking Tray
• Cooking Rack
• Ceramic Cooking Tray
Dimensions
Class Width
30"
Width
29.75 inch(es) / 75.57 cm
Height
19.62 inch(es) / 49.83 cm
Depth
22.37 inch(es) / 56.82 cm
Additional Dimensions
• Required Cutout Size (HxWxD) Standard Install: 19 1/4" x 28 1/2" x 22"
• Required Cutout Size (HxWxD) Flush Install: 20 1/8" x 30" x 23 1/2"
• Required Cutout Size (HxWxD) Flush Install: 20 1/8" x 30" x 23 1/2"
Weight
95.99 lb(s) / 43.54 kg
Warranty
Warranty
Limited 2 Years Parts and Labor
UPC
UPC#
825225941972
