Specifications
General
Series Name
400 Series
Color
Black
Manufacturer Color
Black Glass
Fuel Type
Electric Induction
Type
Built-In
Cooktop
Burners/Elements
4
Power Output
• Burners types (Front-L) - Power (Max/Booster): 1400W / 2100W
• Burners types (Front-R) - Power (Max/Booster): 2300W / 3000W
• Burners types (Rear-L) - Power (Max/Booster): 2300W / 3000W
• Burners types (Rear-R) - Power (Max/Booster): 1400W / 2100W
• Burners types (Front-R) - Power (Max/Booster): 2300W / 3000W
• Burners types (Rear-L) - Power (Max/Booster): 2300W / 3000W
• Burners types (Rear-R) - Power (Max/Booster): 1400W / 2100W
Burner/Element Size
• Burners types (Front-L): 6 - 1/4"
• Burners types (Front-R): 7 - 7/8"
• Burners types (Rear-L): 7 - 7/8"
• Burners types (Rear-R): 6 - 1/4"
• Burners types (Front-R): 7 - 7/8"
• Burners types (Rear-L): 7 - 7/8"
• Burners types (Rear-R): 6 - 1/4"
Burners
Sealed
Elements
Smoothtop
Surface Features
Elegant Ceramic glass surface
Features
Technologies
Premium induction technology
Clock
Yes
Control Lock
Yes
Digital Display
Yes
Additional Information
• Slide touch control for power setting
• Residual heat and Power on Indicators
• Digital Minute Minder
• Pot Detection System
• Melt Function
• Child Lock Function
• Pause function
• Booster function for each cooking zone
• Independent timer for each zone
• Failure Codes Indication
• Digital Display for Power Level
• Automatic Heat-up Time
• Residual heat and Power on Indicators
• Digital Minute Minder
• Pot Detection System
• Melt Function
• Child Lock Function
• Pause function
• Booster function for each cooking zone
• Independent timer for each zone
• Failure Codes Indication
• Digital Display for Power Level
• Automatic Heat-up Time
Electrical Information
Information
• kW / Amps rating at 240V, 60Hz: 7.40kW - 31A
• kW / Amps rating at 208V, 60Hz: 6.40kW - 31A
• kW / Amps rating at 208V, 60Hz: 6.40kW - 31A
Certifications and Approvals
ADA Compliant
Yes
Dimensions
Class Width
30"
Width
30.5 inch(es) / 77.47 cm
Height
2.87 inch(es) / 7.3 cm
Depth
21 inch(es) / 53.34 cm
Weight
35.01 lb(s) / 15.88 kg
Additional Dimensions
• Cut-out - Width: 28 - 3/4"
• Cut-out - Height: 2 - 3/4"
• Cut-out - Depth: 19 - 1/4"
• Cut-out - Height: 2 - 3/4"
• Cut-out - Depth: 19 - 1/4"
