Specifications
General
Series Name
• Plane NRS
• Collection: Silence NRS Series
• Collection: Silence NRS Series
Blower Included
Yes
Airflow
500 CFM
Style
Chimney
Color
Stainless Steel
Manufacturer Color
Scotch brite stainless steel (AISI 304)
Installation
Wall Mount
Features
Technologies
NRS technology for a quieter kitchen
Speeds
4
Additional Information
• Electronic control
• Lighting: LED 2 x 1,2 W - 3200 K
• Air Falmec filter for balanced suction
• Maximum capacity: 610 m³ /h, I.E.C. 61591
• Maximum noise level: 54,5 dB(A)re1pW, I.E.C.60704-2-13
• Maximum pressure: 582 Pa
• Lighting: LED 2 x 1,2 W - 3200 K
• Air Falmec filter for balanced suction
• Maximum capacity: 610 m³ /h, I.E.C. 61591
• Maximum noise level: 54,5 dB(A)re1pW, I.E.C.60704-2-13
• Maximum pressure: 582 Pa
Electrical Information
Information
• 120V, 60Hz
• Maximum consumption: 280 W
• Maximum consumption: 280 W
Accessories
Included
Standard with Nema 5-15P power cord
Optional
• KACL.570#I: Extension H700 - Wall
• KACL.571#I: Extension H960 - Wall
• KACL.815: Protective cleaning cloths for stainless steel (box 10 pcs)
• KACL.921: High Performance Filter
• KACL.571#I: Extension H960 - Wall
• KACL.815: Protective cleaning cloths for stainless steel (box 10 pcs)
• KACL.921: High Performance Filter
Dimensions
Class Width
30"
Width
30 inch(es) / 76.2 cm
Height
23.23 inch(es) / 59 cm
Depth
19.29 inch(es) / 49 cm
Weight
69 lb(s) / 31.3 kg
Additional Dimensions
• Max Height: 43"
• Minimum distance - Gas hob: 25"
• Minimum distance - Electric hob: 21"
• 2 x Metallic filter "Top" - 235 x 306 mm
• Minimum distance - Gas hob: 25"
• Minimum distance - Electric hob: 21"
• 2 x Metallic filter "Top" - 235 x 306 mm
Shipping Dimensions
Width
41 inch(es) / 104.14 cm
Height
27 inch(es) / 68.58 cm
Depth
30 inch(es) / 76.2 cm
Weight
80.01 lb(s) / 36.29 kg
Volume
19 cu. ft.
Warranty
Warranty
1-Year parts and labor
UPC
UPC#
8034122353173
