Features
PERIMETER ASPIRATION
Air is forced through narrow slots around the perimeter of the center panel greatly improving contaminant extraction.
24 HOUR ANTI-POLLUTION MODE
This mode runs the hood for 10 minutes once an hour at a low CFM to refresh the air in your home.
Additional Features
DELAYED AUTO-OFF
Automatically turns the fan off after a set time (varies by the hood).
FILTER SATURATION ALARM
An indicator on the hood signals when to wash filters.
REMOTE CONTROL (INCLUDED)
Control all features of the hood from the convenience of a wireless remote control.
INTENSIVE SPEED
Turns on at the highest speed for 10 minutes.
Specifications
General
Series Name
High-Light
Blower Included
No
Style
Custom Insert
Color
Stainless Steel
Manufacturer Color
Stainless Steel
Installation
Built-In
Features
Dishwasher-Proof Filters
Yes
Ducting Information
• 6" round
• 10" top only
• 4-Way side vent
• 10" top only
• 4-Way side vent
Speeds
4 Speeds (3+ BOOST)
Additional Information
• 300, 400, 600 CFM or remote blower and in-line blowers sold separately
• LED digital touch control
• LED light bar
• Perimetric filter system/ Silent kit
• 24-Hour anti-pollution mode
• 10-Minute intensive speed
• 30-Minute delay auto shut off
• Dishwasher safe mesh grease filter
• Filter wash alarm
• ADA compliant
• LED digital touch control
• LED light bar
• Perimetric filter system/ Silent kit
• 24-Hour anti-pollution mode
• 10-Minute intensive speed
• 30-Minute delay auto shut off
• Dishwasher safe mesh grease filter
• Filter wash alarm
• ADA compliant
Electrical Information
Information
AC power: 400 watts / 3.2 amps
Accessories
Included
ADA compliant remote control
Optional
Blowers:
• IB300 (Internal)
• IB400 (Internal)
• IB600 (Internal)
• RB900 (Remote)
• RB1200 (Remote)
• AXP250 (In-Line)
• FILTER1 – Charcoal Filter Kit • FILTER1LL – Long Lasting Charcoal Filter Kit • FLANGE10 – 10" Plate for External Blower (For use with all remote blowers) • MUDAMPER6 / MUDAMPER8 / MUDAMPER10 – Universal Make-Up Air Damper
• IB300 (Internal)
• IB400 (Internal)
• IB600 (Internal)
• RB900 (Remote)
• RB1200 (Remote)
• AXP250 (In-Line)
• FILTER1 – Charcoal Filter Kit • FILTER1LL – Long Lasting Charcoal Filter Kit • FLANGE10 – 10" Plate for External Blower (For use with all remote blowers) • MUDAMPER6 / MUDAMPER8 / MUDAMPER10 – Universal Make-Up Air Damper
Dimensions
Class Width
36"
Width
35.44 inch(es) / 90.01 cm
Depth
18.5 inch(es) / 46.99 cm
Additional Dimensions
Min / max ceiling height: 5' 11" - 9' (up to 72" above the stove)
Warranty
Warranty
Limited 2 Years
UPC
UPC#
7612985730006
