Features
24 HOUR ANTI-POLLUTION MODE
This mode runs the hood for 10 minutes once an hour at a low CFM to refresh the air in your home.
DISHWASHER SAFE GREASE FILTERS
Multi-layered mesh filters capture grease and allow for easy clean up in the dishwasher.
REMOTE CONTROL (INCLUDED)
Control all features of the hood from the convenience of a wireless remote control.
COMFORT PANEL
The perimetric filtration system improves efficiency and reduces air noise.
DELAYED AUTO-OFF
Automatically turns the fan off after a set time (varies by the hood).
INTENSIVE SPEED
Turns on at the highest speed for 10 minutes.
FILTER SATURATION ALARM
An indicator on the hood signals when to wash filters.
BLOWER FLEXIBILITY
Choose your blower CFM from 300, 400, 600 internal blowers or 900 / 1200 remote blower or in-line blower.
Specifications
General
Series Name
Stratus
Blower Included
No
Style
Island
Color
White
Manufacturer Color
White Glass
Installation
Ceiling Mount
Features
Dishwasher-Proof Filters
Yes
Ducting Information
• 6" round - 4-Way Venting
• 10" Top only
• 10" Top only
Speeds
4
Additional Information
• LED digital touch controls
• 2 x LED light bars
• Perimetric filter system/ Silent kit
• 24 hour anti-pollution mode
• 30 minute delay auto shut off
• 10 minute intensive speed
• Filter wash alarm
• 2 x LED light bars
• Perimetric filter system/ Silent kit
• 24 hour anti-pollution mode
• 30 minute delay auto shut off
• 10 minute intensive speed
• Filter wash alarm
Accessories
Included
ADA compliant remote control
Optional
• Available blowers: IB300, IB400, IB600, RB900, RB1200
• Charcoal filter kit: FILTER1
• Long lasting charcoal filter kit: FILTER1LL
• 10" Plate for remote blower: FLANGE10
• Universal make-up air damper: MUDAMPER6 / MUDAMPER8
• Charcoal filter kit: FILTER1
• Long lasting charcoal filter kit: FILTER1LL
• 10" Plate for remote blower: FLANGE10
• Universal make-up air damper: MUDAMPER6 / MUDAMPER8
Dimensions
Class Width
36"
Width
35.44 inch(es) / 90.01 cm
Depth
19.69 inch(es) / 50.01 cm
Additional Dimensions
• Ceiling cut out: 18-11/16" x 34-9/16"
• Min / max ceiling height: 5' 11" - 9' (up to 72" above the stove)
• Hood width and depth: 35 7/16" W, 18 1/2" D
• Min / max ceiling height: 5' 11" - 9' (up to 72" above the stove)
• Hood width and depth: 35 7/16" W, 18 1/2" D
Warranty
Warranty
Limited 2 Years
UPC
UPC#
7612985459198
