Features
INDUCTION COOKING
Induction technology provides fast and precise results by directly heating pots and pans instead of the cooktop surface

POWER BOOST
Add a boost or double boost of power so you can quickly heat a pan for searing or stir-frying, or boil water fast.

PRECISE TEMPERATURE CONTROL
9 cooking levels put you in control to boil water rapidly or delicately melt chocolate—plus everything in between.

Specifications
General
Color
Black
Manufacturer Color
Frameless Black Glass
Fuel Type
Electric Induction
Type
Built-In
Cooktop
Burners/Elements
3
Power Output
• Front Left Element (Standard / Boost): 2,300 W / 3,700 W
• Rear Left Element (Standard / Max. Boost): 1,400 W / 2,200 W
• Right Element (Standard / Max. Boost): 2,600 W / 3,700 W
• Rear Left Element (Standard / Max. Boost): 1,400 W / 2,200 W
• Right Element (Standard / Max. Boost): 2,600 W / 3,700 W
Burner/Element Size
• Front Left Element (Standard / Boost): 8"
• Rear Left Element (Standard / Max. Boost): 6"
• Right Element (Standard / Max. Boost): 10"
• Rear Left Element (Standard / Max. Boost): 6"
• Right Element (Standard / Max. Boost): 10"
Elements
Smoothtop
Features
Technologies
Induction Technology
Control Lock
Yes
Digital Display
Yes
Additional Information
• Cooking Levels: 9
• On/Off Light
• Digital Display for Power Level Indication
• Timer Display
• Boost Function
• Automatic Pan Detection
• Residual Heat Indicators
• Independent Zone Timers
• Display Lock
• On/Off Light
• Digital Display for Power Level Indication
• Timer Display
• Boost Function
• Automatic Pan Detection
• Residual Heat Indicators
• Independent Zone Timers
• Display Lock
Electrical Information
Information
• Total Power Consumption: 7,400 W
• Volts / Frequency: 220/240 V, 60 Hz
• Min. Circuit Breaker Size: 40 A
• Electrical Connection: Flexible Conduit, 3-Wire or 4-Wire
• Volts / Frequency: 220/240 V, 60 Hz
• Min. Circuit Breaker Size: 40 A
• Electrical Connection: Flexible Conduit, 3-Wire or 4-Wire
Dimensions
Class Width
24"
Width
23.58 inch(es) / 59.9 cm
Height
2.28 inch(es) / 5.8 cm
Depth
20.83 inch(es) / 52.9 cm
Weight
26.46 lb(s) / 12 kg
Additional Dimensions
Required Cutout Size (W x D) (in): 22 1/ 16 x 19 5/ 16
Warranty
Warranty
1 Year
